Token
Buffer – VerilogCSP Model
module TOK_BUF(L,
R);
parameter width = 8;
parameter init = 8’b0;
`INPORT(L,width);
`OUTPORT(R,width);
`USES_CHANNEL
parameter FL = 2;
parameter BL = 4;
reg [width-1:0] d;
initial
begin
`SEND(R,init);
end
always
begin
`RECEIVE(L,d);
#FL;
`SEND(R,d);
#BL;
end
endmodule
}Initial
block
}Mechanism to send out
initial token
}Init
}Value of initial token
sent out
}Configurable via Verilog parameter feature
}After initial block, never
used again
}Always block
}Performs steady-state
behavior
}Just like BUF cell
